Three Phase Dry Type Isolation Transformer-Milky way Transformer Co.,Ltd.

Scope of application

Isolation power supply for industrial equipment

Used for industrial equipment power isolation, voltage matching, and customized dry-type isolation power supply solutions as needed

Multi parameter customized power distribution

Flexible configuration based on primary and secondary voltage, capacity, connection group, shielding, and installation requirements

Safe and Stable Voltage Distribution Scenarios

Isolate interference, block leakage circuits, and ensure stable and safe operation of backend industrial electrical equipment

Product description

Electrical safety isolation: used for industrial equipment to achieve power isolation, block interference and leakage conduction.

Voltage precise matching: Adapt primary and secondary voltages according to operating conditions to meet equipment power supply requirements.

Customized configuration plan: Personalized selection and configuration can be carried out according to capacity, connection group, shielding, and installation requirements.

Dry structure design: Dry body, no need for oil immersion, suitable for indoor industrial scenarios, easy operation and maintenance.

Product features

safe and reliable

Oil free, with strong fire resistance, eliminating the risk of oil leakage; Capable of withstanding short-circuit current and overvoltage, and adapting to harsh environments.

Eco-design

Using environmentally friendly materials, low noise and no pollution, to assist in the construction of a green power grid.

Excellent heat dissipation performance

Efficient cooling system ensures that the equipment maintains low temperature during long-term operation, effectively extending the service life of the equipment.

Convenient operation and maintenance

Humanized design, simple operation, convenient and fast daily inspection and maintenance, significantly reducing operating costs.

Durable and sturdy structure

Durable shell design, impact resistance, corrosion resistance, able to adapt to various complex and harsh working environments.

Convenient and worry free operation and maintenance

Modular structure design, supporting quick disassembly and assembly, combined with intelligent monitoring system, making operation and maintenance work more worry free and effortless.

Technical parameters

Model number	Rated capacity (KVA)	phase number	Rated voltage (V)		Connection group designation	loss（W）		No load current %	Impedance voltage %	weight(kg)	Overall dimensions(mm) Length x Width x Height
Model number	Rated capacity (KVA)	phase number	once （V）	second time （V）	Connection group designation	no-live load	short circuit	No load current %	Impedance voltage %	weight(kg)	Overall dimensions(mm) Length x Width x Height
SG-5/0.5	5	3	380 650 6000 10000	Choose freely according to user requirements	Yy0	75	200	5.5	4	65	430x275x311
SG-10/0.5	10	3			Dyn11	120	256	4.5	3.32	80	470x330x370
SG-15/0.5	15	3			Dyn0	200	450	4	3.5	120	570x470x410
SG-20/0.5	20	3			Dyn11	228	520	3.8	6.5	210	730x260x540
SG-25/0.5	25	3			Dy11	240	570	3.5	3.92	180	650x300x515
SG-30/0.5	30	3			Dyn11	280	680	3.2	3.78	180	650x300x540
SG-35/0.5	35	3			Dyn11	380	820	3	3.61	195	660x300x544
SG-50/0.5	50	3			Yd11.Dd0	450	1100	2.8	3.8	320	880x570x1020
SG-60/0.5	60	3			Yy0	530	1320	2.6	3.5	300	760x570x540
SG-75/0.5	75	3			Yyn0	600	1600	2.5	3.0	370	800x600x625
SG-80/0.5	80	3			Yyn0	720	1720	2.3	3.5	455	1040x650x750
SG-100/0.5	100	3			Yyn0	780	1800	2	4	455	1040x650x750
SG-160/0.5	160	3			Yyn0	1100	2100	1.8	4	870	1210x650x1185
SG-240/10	240	3			YYn0	1500	2300	1.5	4	1180	1250x650x1200
SG-250/15	250	3			Dyn11	1050	3190	1.2	4	1240	1270x650x1305
SG-315/10	315	3			Dyn11	1280	3800	1.1	4	1530	1400x760x1410
SG-400/6	400	3			Dyn11	1590	4550	0.8	4	1850	1460x760x1495
SG-500/0.5	500	3			Yyn0	1400	6400	0.9	4	1778	1400x780x1276
SG-500/10	500	3			Dyn11	1850	5410	0.8	4	2100	1500x780x1595
SG-630/10	630	3			Dyn11	2100	6420	0.6	4	2400	1560x780x1680
SG-800/10	800	3			Yyn0	2200	7630	0.6	6	2600	1640x780x1665
SG-1000/10	1000	3			Yyn0	2540	8850	0.5	6	3150	1720x940x1775
